    Product Details:

    Place of Origin: China
    Brand Name: GL
    Certification: CE
    Model Number: BWING

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Subject to Solutions
    Packaging Details: Aluminum Hard CASE
    Delivery Time: 7 Days
    Payment Terms: T/T
    Supply Ability: 200SETS/Month
    Contact Now
    Detailed Product Description
    Protection Level: IP67 Type: Outlet Box
    Weight: 2.5kg With Battery; 1.6kg Without Battery Flight Duration: 90mins
    Flight Distance: 90Km Materials: EPO And Carbon Fiber
    Body Length: 0.7m Wingspan: 1.5m
    Height: 0.13m Dimensions: 98*36*46CM

    High Accurate Mapping Fixed Wing Drone Easy to Control (RTK Version);Intelligent Thrust Reverse Deceleration Automatical Landing



    1. Smart Planning;Smart Take-Off;Smart Landing

    2. One-man operation/Extraordinary endurance;No need of ground control points(The RTK Edition)

    3. It's really safe,reliable and durable.Really cost-effective for consumers.

    4. Automatic and safe precision landing within a five-merter radius with thrust reverse control algorithm

    Specifications:

    Body Length:0.7m
    Wingspan:1.5m
    Height:0.13m
    Dimensions:98cm*36cm*46cm
    Weight(with Camera):2.5Kg with battery ;1.6Kg without battery
    Battery: 14.8V 10000mah
    Propulsion:500W Motor
    Cruise Speed:70KPH
    Range:90KM
    Weather Limit:6Level Wind and Light Rain
    Maximum Ceiling:4000M
    Control Mode:Auto
    Take off/Landing: Throw into the air/Auto Landing
    Landing Space:5 meters radius circle
    GNSS Reciever: L1/L2 GNSS (GPS,GLonass,Beidou)
    Communication&Control Frequency:915M(FHSS)
    Communication&Control Range:30KM
    Transmit Power:1W

    Precision Parameters

    Standard Camera:Sony ILCE-QX1(20.1million pixels APS-C sensor)
    Standard Lens: Sony E20mm f/2.8
    Maximum Resolution:1.5cm
    Standard 's Absolute Accuracy(No ground control points):
                 Horizontal:0.8M--2M   Vertical: 1M--2.5M
    Standard 's Absolute Accuracy(with  ground control points):
                Horizontal:3CM Vertical: 5CM
    RTK Edition's Absolute Accuracy(No ground control points):
               Horizontal:3CM Vertical: 5CM


    Raletive Accuracy:



     Horizontal :1--3X GSD    Vertical:1--5X GSD


    Area Coverage Table Per Flight

               GSD                               Height                         Area

               1.5cm                               70m                            2.0sq.km
                5.0cm                              235m                          6.1sq.km
               10.0cm                             470m                          11.8sq.km
               15.0cm                             760m                          17.6sq.km
                20.0cm                            940m                          22.2sq.km

    High Accurate  Mapping  Fixed Wing Drone Easy to Control (RTK Version);Intelligent Thrust Reverse Deceleration Landing
    High Accurate  Mapping  Fixed Wing Drone Easy to Control (RTK Version);Intelligent Thrust Reverse Deceleration Landing
