Autonomous Obstacle Avoidance Agricultural Spraying Drone,Carbon Fiber Frame 15Kg Payload with 6 Spray Nozzles

Large Image : Autonomous Obstacle Avoidance Agricultural Spraying Drone,Carbon Fiber Frame 15Kg Payload with 6 Spray Nozzles

Product Details:

Place of Origin:	China
Brand Name:	GL
Certification:	CE
Model Number:	GLF

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Customized
Packaging Details:	Aluminum Hard Case
Delivery Time:	7days
Payment Terms:	TT
Supply Ability:	800SETS/WEEK

Contact Now

Autonomous Obstacle Avoidance Agricultural Spraying Drone,Carbon Fiber Frame 15Kg Payload with 6 Spray Nozzles

Description

Protection Level:	IP67	Type:	Outlet Box
Weight:	16kg	Battery Capacity:	16000mAh
Flying Time:	25Mins	Payload:	15Kg
Color:	Black	Propeller:	30Inches
External Size:	16501650720mm	Max Take Off Weight:	45Kg
Radar:	Autonomous Obstacle Avoidance

Autonomous Agricultural Spraying Drone,Carbon Fiber Frame 15Kg Payload with 6 Spray Nozzles Autonomous Obstacle Avoidance

Specifications Details:

Class	Professional Industrial Class
Take Off Weight	Standard: 35KG
	MTW: 45KG
Hover Accuracy	Hover Time: 25min(16000MA,TW 20KG)
	11min(16000ma TW 35KG)
	Tested by Sea Level;Wind Speed <3m/s
Flight Speed	Max Working Flight Speed:8m/s
	Max Flight Speed:12m/s
Flight Height	ASL 3000m
Wheelbase	1650mm
Recharger	12S Dual 20A
	Recharging Voltage;44V
	Rated Power:1000W
Battery	Power Battery:12S16000ma
Power	Flight
	Rated Power:7920W
	Hover Power :3960W
	RC
	Working Power:9W
Body Parameter
Dimension	Arm length:580mm
	External Size:16501650720mm,(Arms Spread without Propellers)
		680680720mm(Fold Size)
Weight	Complete Body:16KG (Without Battery)
Ambient	Flight Advised Temperature:0C-40C
	RC Working Temperature:-10C-40C
	Storage Temp:Less than 3months,-20C—45C
	More than 3months:22C—28C
	Recharging Temp:0C—40C
Spray System	Spray System
	Tank Capacity:15L
	Working Payload:15KG
	Nozzle:110Angle 001 Fan Nozzle,Flow:0.379L/min
	Advise:Nozzle110Angle 015 Fan Nozzle Flow:0.525L/min
	Numbers:6
	Max Spray Rate:Each110Angle 001 Fan Nozzle 0.43L/min
	Atomizing Particle Size:110Angle001 Fan Nozzle:130-250um
Dynamical System	Motor
	Stator Size:83*20mm
	KV:120rpm/V
	Pull:11..8KG/rotor
	Rated Power :1320W
	Weight:780g
	ESC
	Max Working Current:(Continous )100A
	Working Voltage:50..4V
	Compatible Signal Frequency:621HZ
	Propeller:30inch
	Material:Carbon Fiber
	Dimension:30*10.5inch
	Weight:110g

Video Link:

https://youtu.be/AvFWzTJIDQU

https://youtu.be/k_d2uh4ROIw (Flight In South America)
