Place of Origin: | Shenzhen China |
Brand Name: | GL |
Certification: | CE |
Model Number: | GLH5 |
Minimum Order Quantity: | 1SET |
---|---|
Price: | Negotiable |
Packaging Details: | Aluminium Case |
Delivery Time: | 1week |
Payment Terms: | TT |
Supply Ability: | 500SETS/WEEK |
Max.Payload Capacity: | 5kg | Max.Flight Speed: | 8-15m/s |
---|---|---|---|
Maximum Flight Height: | 5000m | Maximum Flight Time: | 60min |
Video Transmission Distance: | 5-20km | Max Wind Resistance: | 7level |
Police Hexacopter Drone special for inspection and surveillance
Features:
Weight:5.8kg including batteries; Payload:5kg
Vertical Accuracy:±0.1m/s ;Horizon Accuracy:±0.8m/s
60Mins Flight Time;
1080P/60fps real-time 5--15km Video Transmission
Autopilot,5Km Flight Distance
GPS Google Mapping Multi-Point Navigation
Three Flight Modes: Manual Operation,GPS Auto,Hovering
Automatically activated to failsafe mode to back while losing the remote controller signal
Specifications
Weight (Including Battery And Propellers) 5.8kg
Max. Payload capacity 5kg
Diagonal Size (Including Propellers) 1000mm
Max Ascent Speed 5m/s
Max Descent Speed 4m/s
Max Speed 8-15m/s
Max Flight Time 60 mins
ESC:BEST
MOTORS:T MOTOR
Airframe And Horse:Carbon Fibre
Control range:
Video transmit distance 5-15km
Frequency
Max flight height 5000m(altitude)
Hover Accuracy Vertical:< +/- 0.5 m
Horizontal:< +/- 1 m
Max Angular Velocity Pitch: 300°/s
Yaw: 150°/s
Max tilt Angle 35º
Max wind speed resistance 7 Level
Operating Temperature -10° to 50° C
GPS Mode GPS
Camera compatible GH4, songy NeT-5, CANON 5D2/5D3, CMCC designed camera
Gimble JPG03 3-axis gimbal
Angular Vibration range ±0.03°
Mounting detachable
Controllable range Pitch:±360° Pan:±30°
Mechanical Range Pitch/Pan: ±360°
Max Controllable speed Pitch: ±145°/s
Pan: ±145°/s
Remote controller 14CH
Operating Frequency 2.400~2.483 GHz
Max Distance :5km
Operating Temperature 10ºC- 40ºC
7 inch FPV screen included
Receiver Sensitivity (1%PER) >-93dBm
Transmitter Power (EIRP) FCC: 20 dBm CE: 16 dBm
Flight control UPX or UP flight controller
Battery :
6s-Li-Poly 20000mAh
Operating Temperature 0ºC-40ºC
Videos:
https://www.youtube.com/watch?v=O_6WUX9fEzo
https://youtu.be/LY9tySUnUCA
