Home Products VTOL Mapping 18Hours, 380Km Range

Exclusive for Accurate Mapping Fixed Wing Drone Easy to Control (RTK Version) 0.03m Accuracy Mapping Results

Product Details:

Place of Origin:	China
Brand Name:	GL
Certification:	CE
Model Number:	BWING

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Subject to Solutions
Packaging Details:	Aluminum Hard CASE
Delivery Time:	7 Days
Payment Terms:	T/T
Supply Ability:	200SETS/Month

Contact Now

Detailed Product Description

Protection Level:	IP67	Type:	Outlet Box
Weight:	2.5kg With Battery; 1.6kg Without Battery	Flight Duration:	90mins
Flight Distance:	90Km	Materials:	EPO And Carbon Fiber
Body Length:	0.7m	Wingspan:	1.5m
Height:	0.13m	Dimensions:	983646CM

Exclusive for Accurate Mapping Fixed Wing Drone Easy to Control (RTK Version) 0.03m Accuracy Mapping Results

1. Smart Planning;Smart Take-Off;Smart Landing

2. One-man operation/Extraordinary endurance;No need of ground control points(The RTK Edition)

3. It's really safe,reliable and durable.Really cost-effective for consumers.

4. Automatic and safe precision landing within a five-merter radius with thrust reverse control algorithm

Specifications:

Body Length:0.7m

Wingspan:1.5m

Height:0.13m

Dimensions:98cm*36cm*46cm

Weight(with Camera):2.5Kg with battery ;1.6Kg without battery

Battery: 14.8V 10000mah

Propulsion:500W Motor

Cruise Speed:70KPH

Range:90KM

Weather Limit:6Level Wind and Light Rain

Maximum Ceiling:4000M

Control Mode:Auto

Take off/Landing: Throw into the air/Auto Landing

Landing Space:5 meters radius circle

GNSS Reciever: L1/L2 GNSS (GPS,GLonass,Beidou)

Communication&Control Frequency:915M(FHSS)

Communication&Control Range:30KM

Transmit Power:1W

Precision Parameters

Standard Camera:Sony ILCE-QX1(20.1million pixels APS-C sensor)

Standard Lens: Sony E20mm f/2.8

Maximum Resolution:1.5cm

Standard 's Absolute Accuracy(No ground control points):

Horizontal:0.8M--2M Vertical: 1M--2.5M

Standard 's Absolute Accuracy(with ground control points):

Horizontal:3CM Vertical: 5CM

RTK Edition's Absolute Accuracy(No ground control points):

Horizontal:3CM Vertical: 5CM

Raletive Accuracy:

Horizontal :1--3X GSD Vertical:1--5X GSD

Area Coverage Table Per Flight

GSD Height Area

1.5cm 70m 2.0sq.km

5.0cm 235m 6.1sq.km

10.0cm 470m 11.8sq.km

15.0cm 760m 17.6sq.km

20.0cm 940m 22.2sq.km
