    Product Details:

    Place of Origin: China
    Brand Name: GL
    Certification: CE
    Model Number: GLG8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Subject to Solutions
    Packaging Details: WOOD CASE
    Delivery Time: 7 Days
    Payment Terms: T/T
    Supply Ability: 500SETS
    Contact Now
    Detailed Product Description
    Flight Duration: 300mins Flight Distance: 280Km
    Material: SLF Color: Customized

    FIXED-WING Drone GLG8 300mins Flight Time,280Km flight distance ,special for Mapping and  Surveillance



    1. Made by SLF (NEW MATERIALS), nearly indestructible UAV.

    2. Super long cruise duration: 5h. Maximum take off weight: 17kg. Huge amount of separate space and reasonable located the equipment that can be protected well in the inside body.
    3. It’s really safe, reliable and durable. Suit for rough handling in the wild.

    4. Convenient and low cost for following maintenance.

    Materials:SLF;high temperature resistance fibre

    Weight(Kit):4.5Kg

    Weight(RTF):8-12Kg

    Wingspan:2200mm

    Length: 1080mm

    Wing area: 121dm2

    Payload:12-15Kg

    Take off: Throw Go

    Flight Altitude:6000m

    Flight Speed:90km/h

    Flight Duration:300min

    Flight Distance:280Km

    Wind Proof:6 level

    Landing:Parachute or downhill race

    Camera: Nikon-D810 Resolution7360*4912;37M Pixels

    Motor:3525 kv560 *2

    GPS Module:M8N GPS

    ESC: 2*80A

    Propeller: 2*15*7inch Basswood paddle

    Battery: 2*22000mah 6S Li-Po

    Take off weight:12000G



    KIT,ARF,RTF and Optional Accessories


    NO Items Quantity
    1.1 KIT GLG8 Drone 1Set





    1.2 ARF

    GLG8 Drone 1Set
    3525 kv560 Brushless Motor 2Sets
    ESC 2*80A
    17g EMAX analog Servo 3pieces













    1.3 RTF

    GLG8 Drone 1Set
    WFT09II Remote Controller 1 Set
    2*22000mah 6S Li-Po 2Sets
    3525 kv560 Brushless Motor 2Sets
    ESC 2*80A
    17g EMAX analog Servo 3pieces
    15*7inches Folding Contrary-Rotating Wood Propeller 1piece
    Optional Accessories
    2 Improved PIX Flight Control 1set
    3 OSD System 1set
    4 Digital Transmission system 1set
    5 GPS Module:M8N GPS System 1set
    6 Airspeed 1 set
      Amperemeter 1 set
    7 5.8g Image transmission1W+Receiver+antenna System 1set
    8 Camera Nikon D810 1set
    9 Polycom Camera 16G 1set
    10 Link V2 433MHZ 16C RC Range-Extended 1set
    11 7-inch Display Screen all-in-one
    12 10KG Parachute-GLG8 1set
    13 Ground Station Control Center 1 set
    FIXED-WING Drone GLG8 300mins Flight Time,120Km flight distance ,special for Mapping,Surveillnace
    FIXED-WING Drone GLG8 300mins Flight Time,120Km flight distance ,special for Mapping,Surveillnace

    Videos Shares


    Youtube:

                  https://youtu.be/ctcBNakdJGY (New video of the GLG8 landing)

                  https://youtu.be/QwrcJ8IRZno(Fixed-Wing Drone GLG8)



    Notes for SLF Materials:

    SLF is Super light fiber woven material,a new technology material applied in military,agriculture,reconnaissance.It has been totally improved in configuration and function compared with EPO,EPP.Its density is between EPO and EPP,its rigid is 2-3 times than EPO, roughness is 10 times than EPO.Extremely anti-crash,even damaged with regular cut and quick traceless repair with higher strength.Much lighter than other material,more convenient and portable for users and easy maintenance!

    Comparison Test on SLF ,EPO and EPP

    SLF​ VS EPO: new material rigid is 2-3 times than EPO, roughness is 10 times than EPO
    SLF​ VS EPP: new material rigid is 2-3 times than EPP, roughness is 8 times than EPP
    SLF​ VS wooden material: new material rigid is a little bit less than wooden box material, but it is appropriately with wooden box material, but the roughness is much better than wooden box material.
    SLF​ VS glass steel: new material rigid is less than glass steel , but the roughness is much better than glass steel.
