Name: Portable GL-BWING New RTK/PPK Mapping Drone With Catapult 1400MM Wingspan Detachable Take In Back-Bag
Brand: GL
SKU: BWING
Rating: 4.6 (137 reviews)

Home Products VTOL Mapping 18Hours, 380Km Range

Portable GL-BWING New RTK/PPK Mapping Drone With Catapult 1400MM Wingspan Detachable Take In Back-Bag

Product Details:

Place of Origin:	China
Brand Name:	GL
Certification:	CE
Model Number:	BWING

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Subject to Solutions
Packaging Details:	Protection Portable Back Bag
Delivery Time:	7 Days
Payment Terms:	T/T
Supply Ability:	500SETS

Contact Now

Detailed Product Description

Protection Level:	IP67	Type:	Detachable
Weight:	550g	Flight Duration:	90mins
Flight Distance:	80Km	Material:	EPP
Wingspan:	1400MM	PPK/RTK:	Optional

Portable GL-BWING New RTK/PPK Mapping Drone With Catapult 1400MM Wingspan Detachable Take In Back-Bag

1. Integral type body.

2. Portable and suit for rough handling in the wild.

3. It's really safe,reliable and durable.Really cost-effective for consumers.

4. Reasonable located the parachute,camera,flying controller and data transmitter.

Materials:SLF;high temperature resistance fibre

Weight(Kit):550G

Weight(RTF):2.5-3.5Kg

Wingspan:1400mm

Length: 825mm

Flight Control:PIXHAWK Flight Control

Wing area: 30dm2

Payload:2kg

Take off: Throw Go

Flight Altitude:5000m

Flight Speed:65-70km/h

Flight Duration:90mins

Flight Distance:80Km

Wind Proof:6 level

Landing:Parachute or downhill race

Camera:Sony NEX-5N Resolution 4912*3264 HD1080p

Motor:3520 kv700 Brushless Motor

GPS Module:M8N GPS

ESC: 60A

Propeller: 10*8 folding

Battery: 4600mah 6S Li-Po＊2

Take off weight:3500G

YouTube Link:

https://youtu.be/G4TvJJEiTk4
