| Place of Origin: | China |
| Brand Name: | GL |
| Certification: | CE |
| Model Number: | GLF |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Customized |
| Packaging Details: | Aluminum Hard Case |
| Delivery Time: | 7Days |
| Payment Terms: | T/T |
| Supply Ability: | 500SETS/WEEK |
| External Size: | 1400*1400*580mm | Propeller: | 24*8inch |
|---|---|---|---|
| Wheelbase: | 1400mm | Battery Capacity: | 14000mAh |
| Payload: | 20Kg | Flight Duration: | 25mins |
| Complete Body Weight: | 9.8Kg | Radar: | Autonomous Obstacle Avoidance |
Waterproof Carbon Fiber, Agriculture Protection Spray Drone 10kg Payload with Smart Nozzles Autonomously Autonomous Obstacle Avoidance
Specifications Details:
| Class | Professional Industrial Class | |||||
| Take Off Weight | Standard: 35KG | |||||
| MTW: 28KG | ||||||
| Hover Accuracy | Hover Time: 25min(14000MA,TW 14KG) | |||||
| 12min(14000ma TW 24KG) | ||||||
| Tested by Sea Level;Wind Speed <3m/s | ||||||
| Flight Speed | Max Working Flight Speed:8m/s | |||||
| Max Flight Speed:12m/s | ||||||
| Flight Height | ASL 3000m | |||||
| Wheelbase | 1400mm | |||||
| Recharger | 12S Dual 20A | |||||
| Recharging Voltage;44V | ||||||
| Rated Power:1000W | ||||||
| Battery | Power Battery:6S14000ma | |||||
| Power | Flight | |||||
| Rated Power:7920W | ||||||
| Hover Power :4224W | ||||||
| RC | ||||||
| Working Power:9W | ||||||
| Body Parameter | ||||||
| Dimension | Arm length:490mm | |||||
| External Size:1400*1400*580mm,(Arms Spread without Propellers) | ||||||
| 680*680*580mm(Fold Size) | ||||||
| Weight | Complete Body:9.8KG (Without Battery) | |||||
| Ambient | Flight Advised Temperature:0C-40C | |||||
| RC Working Temperature:-10C-40C | ||||||
| Storage Temp:Less than 3months,-20C—45C | ||||||
| More than 3months:22C—28C | ||||||
| Recharging Temp:0C—40C | ||||||
| Spray System | Spray System | |||||
| Tank Capacity:20L | ||||||
| Working Payload:20KG | ||||||
| Nozzle:110Angle 001 Fan Nozzle,Flow:0.379L/min | ||||||
| Advise:Nozzle110Angle 015 Fan Nozzle Flow:0.525L/min | ||||||
| Numbers:3 | ||||||
| Max Spray Rate:Each110Angle 001 Fan Nozzle 0.43L/min | ||||||
| Atomizing Particle Size:110Angle001 Fan Nozzle:130-250um | ||||||
| Dynamical System | Motor | |||||
| Stator Size:62*15mm | ||||||
| KV:170rpm/V | ||||||
| Pull:7.3KG/rotor | ||||||
| Rated Power :1320W | ||||||
| Weight:380g | ||||||
| ESC | ||||||
| Max Working Current:(Continous )60A | ||||||
| Working Voltage:25.2V | ||||||
| Compatible Signal Frequency:50-432HZ | ||||||
| Propeller:24inch | ||||||
| Material:Carbon Fiber | ||||||
| Dimension:24*8inch | ||||||
| Weight:70g | ||||||
