| Place of Origin: | China |
| Brand Name: | GL |
| Certification: | CE |
| Model Number: | GL-Triple |
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | FOB |
| Packaging Details: | Portable Hard Case |
| Delivery Time: | 5Days |
| Payment Terms: | TT |
| Supply Ability: | 300Sets/Week |
| Weight: | 900g | EO;IR: | Yes Integrated |
|---|---|---|---|
| EO: | 10*Zoom | Pixel: | 4.08MP HD |
| IR: | 19mm 640*480 | Calculating: | Target Location Calculating |
| Target Locking: | EO/IR Target Locking Yes | Video: | 128G HD Video |
| Distance Measurement: | 5Km | Compatible With: | DJI And Other Open Source Mavlink Protocol |
New Zoom Triple Camera EO/IR Target Locking 5KM Distance Measurement,Target Location Calculating,4.08MP HD
Detailed Specifications :
| 10*Zoom EO Specifications | |
| Image Sensor | 1/3’ Progressive Scanning CMOS |
| Effective Pixels | 4.08MP |
| Video Output(HD) | 1080P/60 |
| Lens | Auto;Manual;priority mode(shutter/aperture) |
| f=3.2-33.6 | |
| F1.8-3.4 | |
| 640*480 19mm IR Specifications | |
| Uncooled Spectrum Range | 8μm ~ 14μm Thermal Imager |
| Detector Resolution | 640*480 |
| Pixel Spacing | 17μm |
| Palette | White Thermal；Black Thermal；Seudocolor |
| Electric Zoom | 1*; 3* |
| Temperature Measurement | Temperature Bar(Seudocolor Display)Highest Temperature;Lowest Temperature;Central Point Temperature |
| Video Resolution | 1920*1080@60p/50/30p/25p |
| Datas Refresh Rate | 25HZ |
| Targeting Rate | ±32Pixel/Frame |
| Target Dimension | 16*16—128*128 |
| Laser Distance Measurement 5KM | |
